PLAN 888-7
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 49'
Height : 29'
Width : 59'
Area
Bonus : 552 sq/ft
Main Floor : 2168 sq/ft
Ceiling
Ceiling Details : Vaulted Ceiling
Main Ceiling : 10'
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Standing Seam Metal
Secondary Pitch : 3:12
Exterior Wall Framing
Exterior Wall Finish : Board and Batten
Framing : 2x6
Insulation : R31
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Wrap Around Porch
What's Included In This Plan Set
- COVER PAGE: Cover Sheet: Showing architectural rendering of residence
- FOUNDATION PLAN: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- FLOOR PLAN: Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- ROOF PLAN: An overhead "birds-eye" view of the roof, describing roof slope
- ELEVATIONS: A blueprint picture of all four sides showing exterior materials and measurements.
- SECTIONS: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- ELECTRICAL PLAN: Shows the locations of lights, receptacles, switches, etc.
- TYPICAL WALL SECTION & DETAILS
Plan Set
$945.00
$1050.00
$1275.00
$1375.00
$645.00
Foundation
$0.00
$250.00
$250.00
Framing
$0.00
Additional Options
$150.00
$100.00
$295.00
$39.00
$150.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
