PLAN 23-1031
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
This beach design floor plan is 2527 sq ft and has 3 bedrooms and 2.5 bathrooms.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Floor Plan - Upper Floor
Full Specs & Features
Dimension
Depth : 44'
Height : 25' 10"
Width : 66'
Area
First Floor: 2357 sq/ft height 9' 6"
Second Floor: 170 sq/ft height 9' 6"
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 4:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x6"
Bedroom Features
Walk In Closet
Kitchen Features
Eating Bar
Kitchen Island
Additional Room Features
Loft
Lot Characteristics
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Balcony
More
Jack & Jill Bath
Suited For Vacation Home
Rooms
Bedroom 2:
132 sq/ft width 9' 8" x depth 13' 8"
Bedroom 3:
132 sq/ft width 9' 8" x depth 13' 8"
Dining Room:
207 sq/ft width 14' 10" x depth 14'
Family Room:
302 sq/ft width 19' 10" x depth 15' 3"
Home Theater:
338 sq/ft width 19' 4" x depth 17' 6"
Kitchen:
133 sq/ft width 16' x depth 8' 4"
Master Bedroom:
191 sq/ft width 14' 4" x depth 13' 4"
