Plan Description
Contemporary single family home with a traditional floor plan and 2-car garage.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Full Specs & Features
Dimension
Depth : 40' 6"
Height : 21' 4"
Width : 49' 4"
Area
Garage : 503 sq/ft
Main Floor : 1302 sq/ft
Patios : 300 sq/ft
Upper Floor : 1708 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Garage Ceiling : 9' 6"
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : .25/12
Roof Framing : Web Trusses
Roof Load : 25 PSF
Roof Type : Waterproof Membrane
Exterior Wall Framing
Exterior Wall Finish : Hardie Panels
Framing : 2X6
Insulation : R21
Bedroom Features
Main Floor Bedrooms
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Additional Room Features
Great Room Living Room
Upstairs Laundry
Garage Features
Front Entry Garage
Outdoor Spaces
Balcony
Covered Front Porch
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
» See important
information before purchasing.
- Cover Sheet: 3D Rendering and Project Information.
- General Foundation notes (Builder and engineer to provide foundation specs based on lot and local code).
- Floor Plans (lower, main, upper, etc.) showing all doors and windows.
- Elevations from all four sides showing material callouts.
- Wall framing and sectional detail sheets.
- Building Cross Sections showing stair and ceiling height details.
- Window and Door schedule.
- Overhead roof plan showing peaks, valleys, and pitch.
- Foundation Plan showing perimeter and footing details.
- Misc. notes and details.
- *Please note that any structural engineering sheets included with this plan set are for reference only.
