PLAN 301-115
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 79' 9"
Height : 30'
Width : 78' 8"
Area
First Floor: 3020 sq/ft
Roof
Primary Pitch : 16:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Framing : 2"x4"
Bedroom Features
Guest Suite
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Master Sitting Area
Storage Area
Workshop
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Rear Porch
More
Jack & Jill Bath
Rooms
3rd BR Closet:
29 sq/ft width 8' 4" x depth 3' 6"
Bathroom 2:
40 sq/ft width 8' x depth 5'
Bathroom 3:
108 sq/ft width 9' 5" x depth 11' 6"
Bedroom 2:
150 sq/ft width 12' 6" x depth 12'
Bedroom 2 Closet:
17 sq/ft width 2' x depth 8' 8"
Bedroom 3:
144 sq/ft width 11' 4" x depth 12' 9"
Bedroom 3 Closet:
17 sq/ft width 2' x depth 8' 8"
Bedroom 4:
143 sq/ft width 11' 6" x depth 12' 6"
Bedroom 4 Closet:
20 sq/ft width 5' x depth 4'
Breakfast Room:
153 sq/ft width 12' 9" x depth 12'
Dining Room:
192 sq/ft width 12' x depth 16'
Gathering Room:
462 sq/ft width 22' x depth 21'
Kitchen:
240 sq/ft width 15' x depth 16'
Living Room:
163 sq/ft width 11' 8" x depth 14'
Master Bathroom:
191 sq/ft width 16' 8" x depth 11' 6"
Master Bedroom:
270 sq/ft width 15' x depth 18'
Slab Foundation:
6273 sq/ft width 79' 9" x depth 78' 8"
Storage:
59 sq/ft width 3' 6" x depth 17'
Utility Room:
44 sq/ft width 8' x depth 5' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$963.90
$1053.15
$1053.15
$785.40
Foundation
$0.00
Additional Options
$51.00
$85.00
$33.15
$170.00
$51.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
