PLAN 410-122
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 61'
Height : 29'
Width : 79'
Area
First Floor: 1995 sq/ft height 10'
Second Floor: 1077 sq/ft height 9'
Roof
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2"x4"
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Hobby Rec Room Game Room
Loft
Storage Area
Garage Features
Rear Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Balcony
More
Jack & Jill Bath
Rooms
Bedroom 2:
229 sq/ft width 16' x depth 14' 4"
Bedroom 3:
229 sq/ft width 16' x depth 14' 4"
Bedroom 4:
126 sq/ft width 10' x depth 12' 8"
Breakfast Nook:
100 sq/ft width 10' x depth 10'
Dining Room:
213 sq/ft width 16' x depth 13' 4"
Entry:
180 sq/ft width 12' x depth 15'
Game Room:
290 sq/ft width 22' 4" x depth 13'
Kitchen:
147 sq/ft width 12' 4" x depth 12'
Living Room:
377 sq/ft width 22' 8" x depth 16' 8"
Master Bathroom:
172 sq/ft width 15' 8" x depth 11'
Master Bedroom:
250 sq/ft width 15' 8" x depth 16'
Utility Room:
96 sq/ft width 12' x depth 8'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1266.00
$633.00
Foundation
$0.00
Additional Options
$50.00
$100.00
$39.00
$200.00
$60.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
