PLAN 429-346
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 78'
Height : 30' 6"
Width : 64' 7"
Area
First Floor: 2670 sq/ft height 9'
Second Floor: 980 sq/ft height 9'
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchen Island
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Great Room Living Room
Loft
Main Floor Laundry
Media Room
Open Floor Plan
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
Deck
Rooms
Balcony:
82 sq/ft width 18' 3" x depth 4' 6"
Bathroom 2:
64 sq/ft width 11' 3" x depth 5' 9"
Bathroom 3:
56 sq/ft width 9' 9" x depth 5' 9"
Bedroom 2:
171 sq/ft width 14' 3" x depth 12'
Bedroom 2 Closet:
34 sq/ft width 6' x depth 5' 9"
Bedroom 3:
287 sq/ft width 15' 9" x depth 18' 3"
Bedroom 3 Closet:
37 sq/ft width 6' x depth 6' 3"
Breakfast Room:
129 sq/ft width 11' x depth 11' 9"
Coat Closet:
12 sq/ft width 2' 3" x depth 5' 9"
Covered Porch:
287 sq/ft width 30' 3" x depth 9' 6"
Deck:
269 sq/ft width 20' 9" x depth 13'
Dining Room:
206 sq/ft width 14' x depth 14' 9"
Family Room:
311 sq/ft width 19' 9" x depth 15' 9"
Foyer:
206 sq/ft width 14' x depth 14' 9"
Game Room:
129 sq/ft width 9' 3" x depth 14'
Garage:
500 sq/ft width 22' x depth 22' 9"
Keeping Room:
225 sq/ft width 18' 9" x depth 12'
Kitchen:
209 sq/ft width 13' 9" x depth 15' 3"
Kitchen Island:
14 sq/ft width 3' 9" x depth 3' 9"
Laundry Room:
47 sq/ft width 8' 3" x depth 5' 9"
Library:
185 sq/ft width 14' x depth 13' 3"
Master Bathroom:
238 sq/ft width 16' 9" x depth 14' 3"
Master Bedroom:
252 sq/ft width 16' x depth 15' 9"
Master Closet:
54 sq/ft width 7' 6" x depth 7' 3"
Master Closet Two:
52 sq/ft width 7' 3" x depth 7' 3"
Pantry:
11 sq/ft width 5' 3" x depth 2' 3"
Porch - Front:
210 sq/ft width 28' x depth 7' 6"
Powder Room:
35 sq/ft width 6' 3" x depth 5' 9"
Theatre Room:
129 sq/ft width 9' 3" x depth 14'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$900.00
$1000.00
$1250.00
$1250.00
$800.00
Foundation
$0.00
$150.00
$150.00
Framing
$0.00
Additional Options
$65.00
$100.00
$39.00
$200.00
$85.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
