PLAN 951-18
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 47' 8"
Width : 51'
Area
Basement Living: 706 sq/ft
First Floor: 1745 sq/ft
Garage: 832 sq/ft
Second Floor: 1224 sq/ft
Roof
Primary Pitch : 8:12
Roof Framing : Combination Truss/Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Upstairs Master Bedrooms
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Master Sitting Area
Open Floor Plan
Outdoor Spaces
Deck
Rooms
Basement Foundation:
2168 sq/ft width 49' 8" x depth 43' 8"
Bathroom 2:
117 sq/ft width 8' 6" x depth 13' 10"
Bedroom 2:
174 sq/ft width 15' 1" x depth 11' 7"
Bedroom 2 Closet:
14 sq/ft width 7' 2" x depth 2' 1"
Bedroom 3:
191 sq/ft width 12' 8" x depth 15' 1"
Bedroom 3 Closet:
18 sq/ft width 9' x depth 2' 1"
Breakfast Room:
117 sq/ft width 11' 4" x depth 10' 4"
Coat Closet:
8 sq/ft width 3' 11" x depth 2' 1"
Deck:
386 sq/ft width 30' 11" x depth 12' 6"
Den:
139 sq/ft width 10' 5" x depth 13' 5"
Dining Room:
168 sq/ft width 13' 4" x depth 12' 8"
Family Room:
312 sq/ft width 17' 6" x depth 17' 10"
Foyer:
66 sq/ft width 8' x depth 8' 4"
Front Entry:
36 sq/ft width 8' x depth 4' 6"
Garage:
779 sq/ft width 30' 7" x depth 25' 6"
Hall:
88 sq/ft width 25' 11" x depth 3' 5"
Kitchen:
277 sq/ft width 17' 5" x depth 15' 11"
Kitchen Island:
43 sq/ft width 6' 7" x depth 6' 7"
Laundry Room:
67 sq/ft width 10' 3" x depth 6' 7"
Linen Closet:
12 sq/ft width 5' 11" x depth 2' 1"
Living Room:
157 sq/ft width 10' 7" x depth 14' 11"
Master Bedroom:
285 sq/ft width 19' x depth 15'
Parlor:
165 sq/ft width 11' x depth 15'
Porch - Front:
50 sq/ft width 8' x depth 6' 4"
Storage:
130 sq/ft width 10' x depth 13'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1751.00
Foundation
$0.00
Framing
$0.00
Additional Options
$148.75
$51.00
$85.00
$33.15
$170.00
$51.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
