PLAN 542-15
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 44' 8"
Height : 29'
Width : 53'
Area
Garage : 448 sq/ft
Main Floor : 1474 sq/ft
Porch : 119 sq/ft
Upper Floor : 1786 sq/ft
Ceiling
Garage Ceiling : 9' 10"
Main Ceiling : 9' 10"
Upper Ceiling Ft : 14' 8"
Roof
Roof Framing : Wood
Roof Load : Eco-friendly materials
Roof Type : Gable
Exterior Wall Framing
Exterior Wall Finish : Plaster
Framing : Wood
Insulation : Mineral Wool and Wood Fiber Panels
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Wine Cellar
Workshop
Garage Features
Front Entry Garage
Entryway
Friend S Entry
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Suited For View Lot
Zero Lot Lines
Outdoor Spaces
Covered Rear Porch
Outdoor Kitchen Grill
More
Economical To Build
Energy Efficient Features
Energy Efficient Design
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1100.00
$1190.00
$1290.00
$1290.00
$2150.00
$1200.00
Foundation
$0.00
Additional Options
$600.00
$165.00
$39.00
$165.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
