Plan Description


This plan has all the country charm with its large, covered, front porch and cozy, covered patio. As you enter this home, its interior architecture begins to unfold with a large family room complete with a fireplace and entertainment wall and a columned entry to the formal dining room. To the right is the master suite complete with an enclosed shower, a corner tub, His and Hers vanities, a private toilet area and a walk-in closet. To the left is the large kitchen with a walk-in pantry and nook area. The secondary bedrooms are just off the kitchen, each features dual closets. A large laundry is just off the nook area, and the two-car garage is positioned at the rear of the home.

Full Specs & Features


Dimension

Depth : 66' 8"

Height : 20'

Width : 58'

Area

First Floor: 1963 sq/ft height 9'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 7:12

Roof Framing : Truss

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding

Framing : Wood - 2x4

Bedroom Features

Fireplace

Formal Dining Room

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room

Garage Features

Side Entry Garage

Outdoor Spaces

Courtyard

Covered Front Porch

Rooms

Bedroom 2:

121 sq/ft width 11' x depth 11'

Bedroom 3:

147 sq/ft width 12' 4" x depth 12'

Dining Room:

154 sq/ft width 14' x depth 11'

Garage:

441 sq/ft width 21' x depth 21'

Gathering Room:

390 sq/ft width 15' x depth 26'

Kitchen:

96 sq/ft width 12' x depth 8'

Laundry Room:

36 sq/ft width 8' x depth 4' 6"

Master Bathroom:

96 sq/ft width 8' x depth 12'

Master Bedroom:

252 sq/ft width 14' x depth 18'

Storage:

9 sq/ft width 2' x depth 4' 6"
