PLAN 47-775
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 80' 8"
Height : 32'
Width : 67' 8"
Area
First Floor: 2657 sq/ft height 9'
Second Floor: 820 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Living Room / Parlor
Additional Room Features
Den Office Study Computer
Outdoor Spaces
Covered Front Porch
Rooms
3rd BR Closet:
31 sq/ft width 5' 5" x depth 5' 9"
Basement Foundation:
3857 sq/ft width 57' x depth 67' 8"
Bathroom 2:
22 sq/ft width 5' x depth 4' 6"
Bedroom 2:
214 sq/ft width 14' 4" x depth 15'
Bedroom 2 Closet:
56 sq/ft width 7' 2" x depth 7' 10"
Bedroom 3:
186 sq/ft width 13' 4" x depth 14'
Bedroom 3 Closet:
56 sq/ft width 7' 2" x depth 7' 10"
Breakfast Room:
193 sq/ft width 13' 2" x depth 14' 8"
Crawlspace Foundation:
3857 sq/ft width 57' x depth 67' 8"
Den/Office or Bedroom 1:
232 sq/ft width 14' 6" x depth 16'
Dining Room:
196 sq/ft width 14' x depth 14'
Foyer:
78 sq/ft width 13' 6" x depth 5' 10"
Garage:
525 sq/ft width 22' 10" x depth 23'
Hall Bathroom:
70 sq/ft width 5' x depth 14'
Hall Closet:
7 sq/ft width 3' 8" x depth 2'
Kitchen:
176 sq/ft width 12' x depth 14' 8"
Living Room:
418 sq/ft width 19' x depth 22'
Master Bathroom:
168 sq/ft width 16' 10" x depth 10'
Master Bedroom:
280 sq/ft width 20' x depth 14'
Master Closet:
61 sq/ft width 6' 2" x depth 10'
Porch - Front:
26 sq/ft width 5' x depth 5' 4"
Porch - Rear:
142 sq/ft width 9' 6" x depth 15'
Powder Room:
18 sq/ft width 6' x depth 3'
Utility Room:
49 sq/ft width 6' 2" x depth 8'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1358.28
$1496.88
$1635.48
$1635.48
$2716.56
Foundation
$0.00
$0.00
$275.00
$275.00
Framing
$0.00
Additional Options
$195.00
$60.00
$495.00
$150.00
$395.00
$39.00
$150.00
$85.00
$0.00
$995.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
