PLAN 70-665
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 55' 4"
Height : 26' 3"
Width : 65'
Area
First Floor: 1960 sq/ft
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x6"
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Hobby Rec Room Game Room
Storage Area
Garage Features
Oversized Garage
Lot Characteristics
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bedroom 2:
132 sq/ft width 11' 8" x depth 11' 4"
Bedroom 2 Closet:
16 sq/ft width 8' x depth 2'
Bedroom 3:
126 sq/ft width 11' 8" x depth 10' 10"
Bedroom 3 Closet:
11 sq/ft width 5' 7" x depth 2'
Dining Room:
160 sq/ft width 12' 8" x depth 12' 8"
Family Room:
268 sq/ft width 19' 2" x depth 14'
Foyer:
67 sq/ft width 6' 8" x depth 10' 2"
Garage:
675 sq/ft width 31' 8" x depth 21' 4"
Hall:
74 sq/ft width 21' 4" x depth 3' 6"
Hall Bathroom:
40 sq/ft width 8' x depth 5'
Hall Closet:
7 sq/ft width 3' 10" x depth 2'
Kitchen:
105 sq/ft width 8' 4" x depth 12' 8"
Laundry Room:
38 sq/ft width 8' x depth 4' 10"
Master Bathroom:
132 sq/ft width 10' 2" x depth 13'
Master Bedroom:
132 sq/ft width 11' 8" x depth 11' 4"
Master Closet:
60 sq/ft width 6' 2" x depth 9' 10"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$855.10
$901.00
$1068.45
$1068.45
$1699.15
Foundation
$0.00
$335.75
$335.75
Additional Options
$335.75
$68.00
$85.00
$250.75
$33.15
$63.75
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
