PLAN 17-2414
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 73' 4"
Height : 28' 5"
Width : 58' 6"
Area
Bonus: 546 sq/ft height 8'
First Floor: 2001 sq/ft height 9'
Garage: 586 sq/ft
Porch: 367 sq/ft
Second Floor: 651 sq/ft height 8'
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 10:12
Roof Framing : stick
Roof Load : 45
Roof Type : shingle
Exterior Wall Framing
Exterior Wall Finish : Shingle/Stone
Framing : 2"x4"
Insulation : R13
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Play Flex Room
Storage Area
Unfinished Future Space
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Rooms
Bedroom 2:
130 sq/ft width 11' 6" x depth 11' 4"
Bedroom 3:
177 sq/ft width 14' 10" x depth 12'
Bedroom 4:
253 sq/ft width 12' 8" x depth 20'
Bonus Room - Unfinished:
431 sq/ft width 10' 10" x depth 39' 10"
Breakfast Room:
158 sq/ft width 15' 10" x depth 10'
Covered Porch:
160 sq/ft width 20' x depth 8'
Dining Room:
140 sq/ft width 11' 8" x depth 12'
Foyer:
61 sq/ft width 7' 8" x depth 8'
Garage:
528 sq/ft width 22' 6" x depth 23' 6"
Great Room:
408 sq/ft width 22' 8" x depth 18'
Grilling Porch:
184 sq/ft width 23' x depth 8'
Kitchen:
196 sq/ft width 15' 10" x depth 12' 5"
Master Suite:
280 sq/ft width 18' 8" x depth 15'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
Plan Set
$1100.00
$1200.00
$1450.00
$1800.00
$2200.00
$2200.00
Foundation
$0.00
$0.00
$299.00
$299.00
Framing
$0.00
$299.00
Additional Options
$299.00
$80.00
$100.00
$395.00
$39.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
