PLAN 70-1477
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Smart design choices make this house plan live large. The open floor plan between the kitchen and great room creates an easygoing flow and allows the home to feel larger than it is. A fireplace warms the great room and adds cozy charm. Owners will enjoy their private master suite and spacious walk-in closet. Need to stay organized? Lockers just off the three-car garage provide a place to put items during busy transitions. Other highlights we love: the generous walk-in pantry and outdoor living space. This plan is not available for construction in any zip code within a 30 mile radius of Urbandale, IA. This includes the following zip codes: 50001, 50003, 50007, 5009-50014, 50021, 50023, 50032, 50033, 50035, 50037-50039, 50046. 50047, 50054, 50055, 50061, 50063, 50066, 50069, 50070, 50072, 50073, 50109, 50111, 50118, 50124, 50125, 50134, 50146, 50152, 50156, 50160, 50161, 50166-50169, 50211, 50218, 50220, 50226, 50228, 50229, 50233, 50237, 50240, 50241, 50243, 50244, 50250, 50261, 50263, 50265, 50266, 50273, 50276, 50301-50323, 50325, 50327-50336, 50338-50340, 50347, 50350, 50359-50364, 50367-50369, 50380, 50381, 50391-50398, 50936, 50940, 50947, 50950, 50980, 50981.
Floor Plans
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 64' 4"
Height : 0"
Width : 58'
Area
Garage : 617 sq/ft
Main Floor : 1837 sq/ft
Porch : 195 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : 11' ceiling in Great Room & Foyer; 9' to 10' step ceiling in Dining Area & Master Bedroom
Main Ceiling : 9' 1"
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Load : 45 psf
Roof Type : Shingle
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Stone/Siding
Framing : 2 x 6
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Mud Room
Garage Features
Front Entry Garage
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bedroom 2:
width 10' 8" x depth 11' 8"
Bedroom 3:
width 10' 8" x depth 12' 4"
Dining Room:
width 11' 4" x depth 11' 8"
Great Room:
width 15' 8" x depth 20' 4"
Kitchen:
width 11' 4" x depth 15'
Master Bedroom:
width 15' x depth 13' 4"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Questions? Call 1-888-447-1946
Plan Set
5 Copy Set:
$1006.00
$1006.00
5 printed plan sets mailed to you.
8 Copy Set:
$1060.00
$1060.00
8 printed plan sets mailed to you.
PDF Set:
$1257.00
$1257.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set:
$1257.00
$1257.00
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
CAD Set:
$1999.00
$1999.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Foundation
Basement:
$0.00
$0.00
Ideal for level lot, lower level of home partially or fully underground.
Crawlspace:
$395.00
$395.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Slab:
$395.00
$395.00
Ideal for level lot, single layer concrete poured directly on grade.
Framing
Wood 2x6:
$0.00
$0.00
Wood 2x6 Exterior Walls
Additional Options
Right-Reading Reverse:
$395.00
$395.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets:
$80.00
$80.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design:
$100.00
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Comprehensive Material List:
$295.00
$295.00
A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.
Construction Guide:
$39.00
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Mirror Reversed Sets:
$75.00
$75.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
