PLAN 17-2901
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 58'
Height : 24' 6"
Width : 70'
Area
First Floor: 1982 sq/ft height 9'
Garage: 588 sq/ft
Porch: 318 sq/ft
Roof
Primary Pitch : 10:12
Roof Type : Shingle
Exterior Wall Framing
Framing : Wood - 2x4
Bedroom Features
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Kitchen Features
Kitchen Island
Additional Room Features
Great Room Living Room
Main Floor Laundry
Sunroom
Outdoor Spaces
Screened Porch
Rooms
Bedroom 2:
168 sq/ft width 14' x depth 12'
Bedroom 3:
168 sq/ft width 14' x depth 12'
Breakfast Room:
121 sq/ft width 14' x depth 8' 8"
Covered Porch:
169 sq/ft width 21' 2" x depth 8'
Dining Room:
175 sq/ft width 14' x depth 12' 6"
Foyer:
102 sq/ft width 17' x depth 6'
Garage:
535 sq/ft width 22' 4" x depth 24'
Great Room:
311 sq/ft width 17' x depth 18' 4"
Kitchen:
165 sq/ft width 14' x depth 11' 10"
Laundry Room:
69 sq/ft width 8' x depth 8' 8"
Master Bathroom:
108 sq/ft width 9' 4" x depth 11' 8"
Master Suite:
228 sq/ft width 12' 8" x depth 18'
Porch - Screened:
136 sq/ft width 17' x depth 8'
Storage:
27 sq/ft width 9' 4" x depth 3'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
Plan Set
$680.00
$765.00
$977.50
$1275.00
$1360.00
$1360.00
